| Producto | CPU Socket / Chipset |
|---|---|
| ● CPU: LGA1700 socket supports 12th/13th generation Alder Lake-S/Raptor Lake-S Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron® Processor (up to 65W TDP CPU) ● Chipset: Intel® H610/H610E |
|
| ● CPU: LGA1700 socket supports 12th/13th generation Alder Lake-S/Raptor Lake-S Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron® Processor (up to 65W TDP CPU) ● Chipset: Intel® H610/H610E |
|
| ● CPU: LGA1700 socket supports 12th/13th generation Alder Lake-S/Raptor Lake-S Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron® Processor (up to 125W TDP CPU) ● Chipset: Intel®Q670/Q670E |
|
| CPU: LGA1700 socket supports 12th generation Alder Lake-S Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron® Processor (up to 125W TDP CPU) Chipset: Intel®R680E |
|
| ● CPU: LGA1700 socket supports 12th/13th generation Alder Lake-S/Raptor Lake-S Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron® Processor (up to 65W TDP CPU) ● Chipset: Intel® H610/H610E |
|
| Intel® Elkhart Lake Processor Intel® Celeron® J6412 on-board SoC (up to 2.6GHz, quad-core, 1.5M Cache, TDP=10W) |
|
| 11th generation Intel® mobile Tiger Lake-UP3 on-board processor | |
| CPU: 10 th / 11 th Generation LGA1200 Intel® Core™ i9/i7/i5/i3, Celeron® and Pentium® processors Chipset: Intel® Q470/Q470E |
|
| CPU: LGA1200 Intel® 10th Generation Core™ i9/i7/i5/i3, Celeron® and Pentium® processor Chipset: Intel® H420E |
|
| CPU: LGA1200 Intel® 10th/11th Generation Core™ i9/i7/i5/i3, Celeron® and Pentium® processor Chipset：Intel® H420E |
| Producto | CPU Socket / Chipset |
Memory | I/O / Slot | Features |
|---|---|---|---|---|
| ● CPU: LGA1700 socket supports 12th/13th generation Alder Lake-S/Raptor Lake-S Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron® Processor (up to 65W TDP CPU) ● Chipset: Intel® H610/H610E |
Two 288-pin Dual-Channel DDR4 (up to 3200 MHz) SDRAM Unbuffered DIMMs supported up to 64GB | ● External I/O Interface： 2 x USB 3.2 Gen2 x1 (Type-A) (10Gb/s) 2 x USB 3.2 Gen1 x1 (Type-A) (5Gb/s) 4 x USB 2.0 (Type-A) 2 x RS-232/422/485 (RS-485 support AFC) ● Internal I/O Interface： 4 x SATA 6Gb/s 2 x USB 2.0 (2x4 pin, P=2.54) 4 x RS-232 (2x5 pin, P=2.54) |
1 x PCIe Gen4 x16 1 x PCIe Gen3 x4 open-end 2 x PCIe Gen3 x1 1 x M.2 M Key 2280( PCIe x1 ) NVMe supported |
|
| ● CPU: LGA1700 socket supports 12th/13th generation Alder Lake-S/Raptor Lake-S Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron® Processor (up to 65W TDP CPU) ● Chipset: Intel® H610/H610E |
Two 288-pin Dual-Channel DDR4 (up to 3200 MHz) SDRAM Unbuffered DIMMs supported up to 64GB | ● External I/O Interface： 2 x USB 3.2 Gen2 x1 (Type-A) (10Gb/s) 2 x USB 3.2 Gen1 x1 (Type-A) (5Gb/s) 4 x USB 2.0 (Type-A) 2 x RS-232/422/485 (RS-485 support AFC) ● Internal I/O Interface： 4 x SATA 6Gb/s 2 x USB 2.0 (2x4 pin, P=2.54) 4 x RS-232 (2x5 pin, P=2.54) |
1 x PCIe Gen4 x16 1 x PCIe Gen3 x4 open-end 2 x PCIe Gen3 x1 2 X PCI |
|
| ● CPU: LGA1700 socket supports 12th/13th generation Alder Lake-S/Raptor Lake-S Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron® Processor (up to 125W TDP CPU) ● Chipset: Intel®Q670/Q670E |
Four 288-pin Dual-Channel DDR4 (up to 3200 MHz) SDRAM Unbuffered DIMMs supported up to 128GB | ● External I/O Interface： 4 x USB 3.2 Gen2 x1 (Type-A) (10Gb/s) 2 x USB 3.2 Gen1 x1 (Type-A) (5Gb/s) 2 x RS-232/422/485 (RS-485 support AFC) ● Internal I/O Interface： 4 x SATA 6Gb/s 2 x USB 3.2 Gen1 (2 x 10pin, P=2.00 pin wafer) (5Gb/s) 4 x USB 2.0 (2 x 4 pin, P=2.54) 4 x RS-232 (2 x 5 pin, P=2.54) |
**1 x PCIe Gen4 x16 slot **1 x PCIe Gen4 x4 open-end slot 2 x PCIe Gen4 x4 open-end slot 2 x PCIe Gen3 x1 slot 1 x PCI slot 1 x M.2 M Key (2242/2280, PCIe x4 ) NVMe support 1 x M.2 M Key (2242/2280, PCIe x2 for SSD) NVMe support |
|
| CPU: LGA1700 socket supports 12th generation Alder Lake-S Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron® Processor (up to 125W TDP CPU) Chipset: Intel®R680E |
Four 288-pin Dual-Channel DDR5 (up to 4400 MHz) SDRAM Unbuffered DIMMs supported up to 128GB (ECC&non-ECC support) | External I/O Interface： 4 x USB 3.2 Gen2 (Type-A) (10Gb/s) 2 x USB 3.2 Gen1 (Type-A) (5Gb/s) 2 x RS-232/422/485 (RS-485 support AFC) Internal I/O Interface： 4 x SATA 6Gb/s (RAID 0/1/5/10 supported) 4 x USB 2.0 (2x4 pin, P=2.00) 2 x USB 3.2 Gen1 (2 X 10PIN P=2.00 pin wafer) (5Gb/s) 4 x RS-232 (2x5 pin, P=2.54) |
** 2 x PCIe Gen5 x16 slot with x8 Signal ** 1 x PCIe Gen4 x4 open-end 2 x PCIe Gen4 x4 open-end 2 x PCIe Gen3 x1 2 x M.2 M Key (2242/2280, PCIe x4) NVMe supported |
|
| ● CPU: LGA1700 socket supports 12th/13th generation Alder Lake-S/Raptor Lake-S Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron® Processor (up to 65W TDP CPU) ● Chipset: Intel® H610/H610E |
Two 260-pin Dual-Channel DDR4 (up to 3200 MHz) SDRAM Unbuffered DIMMs supported up to 64GB | ● External I/O Interface： 2 x USB 3.2 Gen2 x1 (Type-A) (10Gb/s) 2 x USB 3.2 Gen1 x1 (Type-A) (5Gb/s) 2 x USB 2.0 (Type-A) 2 x RS-232/422/485 (RS-485 support AFC) ● Internal I/O Interface： 2 x SATA 6Gb/s 2 x USB 2.0 (2x4 pin, P=2.0) 4 x RS-232 (2x5 pin, P=2.0) |
1 x PCIe Gen4 x16 1 x M.2 M key (2280, PCIe Gen3 X 4) 1 x M.2 A key (2230, PCIe Gen3 x1 &USB 2.0) |
|
| Intel® Elkhart Lake Processor Intel® Celeron® J6412 on-board SoC (up to 2.6GHz, quad-core, 1.5M Cache, TDP=10W) |
Onboard LPDDR4x-3200MHz 8GB, system up to 16GB | External I/O Interface : 2 x USB 3.2 Gen2 (10Gb/s) (USB Type A) 2 x USB 2.0 (USB Type A) 2 x RS-232 Internal I/O Interface : 1 x SATA 6Gb/s 4 x USB 2.0 (2x4 pin, P=2.0) 4 X RS-422/485 (1x4 pin,P=2.0) |
1 x PCIe x4 Slot Open-ended (PCIe Gen3 x1 signal) 1 x M.2 A key (2230) (PCIex1 & USB 2.0) 1 x M.2 B key (3052/3042/2242/2280) w/ SIM holder (PCIe x2 / USB 2.0) |
|
| 11th generation Intel® mobile Tiger Lake-UP3 on-board processor | Two 260-pin 3200 MHz DDR4 SO-DIMM slots (system max. 64 GB) |
External I/O Interface: 4 x USB 3.2 Gen2 (10Gb/s) by USB Type-C Internal I/O Interface: 2 x SATA 6Gb/s (Support RAID 0/1) 2 x USB 2.0 (2x4 pin, P=2.0) 1 x RS-422/485 by 4-pin (1x4) wafer (RS-485 supports AFC) 5 x RS-232 by 10-pin header (2x5 pin, P=2.0) |
1 x PCIe x8 slot (PCIe 4.0 with x4 signal, open-ended) 1 x M.2 2230 A-key slot (PCIe x1 & USB 2.0) 1 x M.2 2242/2280 M-key slot (PCIe x2) |
|
| CPU: 10 th / 11 th Generation LGA1200 Intel® Core™ i9/i7/i5/i3, Celeron® and Pentium® processors Chipset: Intel® Q470/Q470E |
Four 288-pin 2933 MHz dual-channel unbuffered DDR4 SDRAM DIMM slots supporting up to 128 GB memory | External I/O Interface: 1 x RS-232 DB-9 2 x USB 2.0 (Type-A) 2 x USB 3.2 Gen 1 (5Gb/s) (Type-A) 2 x USB 3.2 Gen 2 (10Gb/s) (Type-A) Internal I/O Interface: 6 x USB 2.0 (2x4 pin, p=2.54) 2 x USB 3.2 Gen1 (2x10 pin, p=2.0) 2 x RS-232 (2x5 pin, p=2.54) 1 x RS-422/485 (1x4 pin, p=2.0) |
2 x PCIe Gen3 x16 (x8 signal） 3 x PCIe Gen3 x4 2 x PCIe Gen3 x1 M.2 M key (2242/2280) with PCIe x2 & SATA signal |
|
| CPU: LGA1200 Intel® 10th Generation Core™ i9/i7/i5/i3, Celeron® and Pentium® processor Chipset: Intel® H420E |
Two 260-pin 2933 MHz Dual-Channel DDR4 SO-DIMMs supported up to 64GB | External I/O Interface: 2 x RS-232 2 x USB 2.0 4 x USB 3.2 Gen1 (5Gb/s) Internal I/O Interface: 1 x RS-232 (2x5 pin, P=2.0) 1 x RS-422/485 (1x4 pin, P=2.0) 2 x USB 2.0 (2x4 pin, P=2.0) 2 x SATA 6Gb/s (No RAID) |
1 x PCIe Gen3 x16 1 x M.2 A key (2230) (PCIe Gen 3 x1/USB 2.0) 1 x M.2 B key (3042/3052/2242/2280) w/ SIM holder (PCIe Gen 3 x2 /USB 2.0) |
|
| CPU: LGA1200 Intel® 10th/11th Generation Core™ i9/i7/i5/i3, Celeron® and Pentium® processor Chipset：Intel® H420E |
Two 288-pin 2933 MHz Dual-Channel DDR4 SDRAM Unbuffered DIMMs supported up to 64GB | External I/O Interface: 4 x USB 3.2 Gen 1 (5Gb/s) 2 x USB 2.0 1 x RS-232 1 x KB/MS Internal I/O Interface: 1 x RS-232/422/485 (2x5 pin, P=2.54) 2 x USB 2.0 (2x4 pin, P=2.54) 4 x RS-232 (2x5 pin, P=2.54) 4 x SATA 6Gb/s (no RAID) |
1 x PCIe Gen3 x16 1 x PCIe Gen3 x4 4 x PCI |
IMB-ADL-H610
